Java Singleton Design Pattern (Creational Pattern)

Mastering the Singleton Design Pattern in Java

Introduction

The Singleton Design Pattern ensures that a class has only one instance and provides a global point of access to that instance. It is part of the creational design patterns and is widely used in scenarios where a single object needs to coordinate actions across the system.


Implementing the Singleton Pattern

Let's look at a basic implementation of the Singleton pattern.

public class Singleton {
    private static volatile Singleton instance;
    private String data;

    private Singleton(String data) {
        this.data = data;
    }

    public static Singleton getInstance(String data) {
        Singleton result = instance;
        if (result == null) {
            synchronized (Singleton.class) {
                result = instance;
                if (result == null) {
                    instance = result = new Singleton(data);
                }
            }
        }
        return result;
    }

    public String getData() {
        return data;
    }

    public void setData(String data) {
        this.data = data;
    }
}

Explanation:

  • Private Constructor: Prevents instantiation from outside the class.
  • Volatile Instance: Ensures visibility of changes to variables across threads.
  • Double-Checked Locking: Minimizes synchronization overhead by locking only when the instance is null.
  • Getter and Setter: Methods to access and modify the data field.

Main Method to Test Singleton

public class SingletonMain {
    public static void main(String[] args) {
        Singleton instance1 = Singleton.getInstance("Initial data");
        System.out.println(instance1);  // Output: Singleton{data='Initial data'}

        // Updating the data
        instance1.setData("Updated data");
        System.out.println(instance1);  // Output: Singleton{data='Updated data'}

        Singleton instance2 = Singleton.getInstance("Another data");
        System.out.println(instance2);  // Output: Singleton{data='Updated data'}
        System.out.println(instance1 == instance2);  // should print true
    }
}


Handling Serialization Issues

Serialization can break the Singleton pattern by creating a new instance upon deserialization. To resolve this, implement the readResolve method:


import java.io.ObjectStreamException;
import java.io.Serializable;

public class Singleton implements Serializable {
    private static volatile Singleton instance;
    private String data;

    private Singleton(String data) {
        this.data = data;
    }

    public static Singleton getInstance(String data) {
        Singleton result = instance;
        if (result == null) {
            synchronized (Singleton.class) {
                result = instance;
                if (result == null) {
                    instance = result = new Singleton(data);
                }
            }
        }
        return result;
    }

    private Object readResolve() throws ObjectStreamException {
        return getInstance(data);
    }
}

Explanation:

  • readResolve Method: Ensures that the deserialized object returns the existing instance.

Main Method for Serialization Test

import java.io.*;

public class SingletonSerializationTest {
    public static void main(String[] args) {
        try {
            Singleton instance1 = Singleton.getInstance("data");

            // Serialize the instance
            ObjectOutputStream out = new ObjectOutputStream(new FileOutputStream("singleton.ser"));
            out.writeObject(instance1);
            out.close();

            // Deserialize the instance
            ObjectInputStream in = new ObjectInputStream(new FileInputStream("singleton.ser"));
            Singleton instance2 = (Singleton) in.readObject();
            in.close();

            System.out.println(instance1);
            System.out.println(instance2);
            System.out.println(instance1 == instance2);  // should print true

        } catch (IOException | ClassNotFoundException e) {
            e.printStackTrace();
        }
    }
}

Expected Output:

Singleton@1517365b
Singleton@1517365b
true


Preventing Singleton Breakage via Reflection

Reflection can break the Singleton pattern by accessing the private constructor. Prevent this by throwing an exception if an instance already exists:

public class Singleton {
    private static volatile Singleton instance;
    private String data;

    private Singleton(String data) {
        if (instance != null) {
            throw new RuntimeException("Use getInstance() method to get the single instance of this class.");
        }
        this.data = data;
    }

    public static Singleton getInstance(String data) {
        Singleton result = instance;
        if (result == null) {
            synchronized (Singleton.class) {
                result = instance;
                if (result == null) {
                    instance = result = new Singleton(data);
                }
            }
        }
        return result;
    }

    public String getData() {
        return data;
    }

    public void setData(String data) {
        this.data = data;
    }
}

Explanation:

  • RuntimeException in Constructor: Prevents instantiation via reflection.

Main Method for Reflection Test

import java.lang.reflect.Constructor;

public class SingletonReflectionTest {
    public static void main(String[] args) {
        try {
            Singleton instance1 = Singleton.getInstance("data");

            Constructor<Singleton> constructor = Singleton.class.getDeclaredConstructor(String.class);
            constructor.setAccessible(true);
            Singleton instance2 = constructor.newInstance("data");

        } catch (Exception e) {
            System.out.println(e.getMessage());
        }
    }
}

Expected Output:

Use getInstance() method to get the single instance of this class.


Multithreading in Singleton Pattern

Let's test our Singleton implementation in a multithreaded environment:

public class SingletonThreadTest {
    public static void main(String[] args) {
        Runnable task = () -> {
            Singleton singleton = Singleton.getInstance("data");
            System.out.println(Thread.currentThread().getName() + ": " + singleton.hashCode());
        };

        Thread thread1 = new Thread(task);
        Thread thread2 = new Thread(task);
        Thread thread3 = new Thread(task);

        thread1.start();
        thread2.start();
        thread3.start();
    }
}

Expected Output:

Thread-0: 12345678
Thread-1: 12345678
Thread-2: 12345678


Class Diagram of Singleton Creational Pattern


Usecase of Singleton Design Pattern:

Database Connection Pool

Managing database connections efficiently is crucial for the performance of an application. A connection pool ensures that multiple connections to the database are reused rather than created and destroyed repeatedly. A Singleton pattern can be used to manage the connection pool.

Example:

import java.sql.Connection;
import java.sql.DriverManager;
import java.sql.SQLException;
import java.util.ArrayList;
import java.util.List;

public class ConnectionPool {
    private static volatile ConnectionPool instance;
    private List<Connection> availableConnections = new ArrayList<>();
    private static final int MAX_CONNECTIONS = 10;

    private ConnectionPool() {
        // Initialize the connection pool with connections
        for (int i = 0; i < MAX_CONNECTIONS; i++) {
            try {
                availableConnections.add(DriverManager.getConnection("jdbc:yourdatabaseurl", "username", "password"));
            } catch (SQLException e) {
                e.printStackTrace();
            }
        }
    }

    public static ConnectionPool getInstance() {
        if (instance == null) {
            synchronized (ConnectionPool.class) {
                if (instance == null) {
                    instance = new ConnectionPool();
                }
            }
        }
        return instance;
    }

    public synchronized Connection getConnection() {
        if (availableConnections.isEmpty()) {
            throw new RuntimeException("No available connections");
        }
        return availableConnections.remove(0);
    }

    public synchronized void releaseConnection(Connection connection) {
        availableConnections.add(connection);
    }
}

// Usage
public class Main {
    public static void main(String[] args) {
        ConnectionPool pool = ConnectionPool.getInstance();
        Connection conn = pool.getConnection();

        // Use the connection
        // ...

        pool.releaseConnection(conn);
    }
}

Above example illustrate how the Singleton pattern can be applied in realtime scenario to ensure only one instance of a class is created and shared across the application, providing a global point of access.


Conclusion

The Singleton Design Pattern is a powerful tool for ensuring a class has only one instance and provides a global point of access to it. By handling potential issues like serialization and reflection, and ensuring thread safety, we can implement a robust Singleton pattern in Java.

I hope you found this post insightful.
For more design patterns, visit https://techinsightswithamrish.blogspot.com.
